ShopNotes #79 2005-01-01

January 2005
Issue 79

Read Online

Subscribe to ShopNotes magazine

Subscribe Today

Subscription Options

Get a Digital Subscription

Contact our Customer Service

Table of Contents

Readers' Tips4

Straight Bits8

We give you the straight scoop on straight bits. You'll be surprised at all there is to know.

  • Page 8: Photo of bit, lower left corner
    The photo is a mirror image of the bit.

4 Favorite Fasteners10

Keeping a good supply of hardware on hand is a must. Here are four fasteners to keep in stock.

  • Page 11: Confirmat screw photo
    The threads are backwards.

Leigh Dovetail Jig12

The ultimate dovetail jig? Considering what you can do with this dovetail jig, you bet.

Shop Short Cuts16

Shop-tested tips and techniques to solve your woodworking problems.

Slant-Front Tool Cart18

Keep all your tools and supplies close at hand with this roll-around tool cart. There's even a matching tool chest you can build.

  • Page 25: Ripping Narrow Strips illustration
    The splitter is shown as being 1/4" but it should be 1/8".
  • Page 26: Figure 3
    The gap around the drawer false fronts is printed as 1/8" but it should be 1/16".

Online Extras

  • Slant-Front Tool Cart
    Store a shopful of tools and keep them right where you need them with this roll-around tool cart.

Edging with T-Molding28

Cover and protect the edge of plywood and MDF. T-molding makes it quick and easy.

Dado Blade Storage Case30

With just a couple hours of work, you can make a handy storage case to protect your stack dado set when it's not being used.

  • Page 31: Main illustration
    The location of the hole for the T-nut should be 2-1/2" in from the edge of the Center Panel (C). The distance from the bottom of the panel should be 7-3/4".
  • Page 31: Illustration for Setting the Boundary
    The location of the center of the holes for the handle should be 1" from the top edge.
  • Page 31: Text
    The last sentence of the final paragraph should read "...I routed the sharp edges of the cutout with a 1/8" roundover bit."

Brass-Body Hand Plane32

Nothing quite beats the feel of using a hand plane you've made yourself. And this brass-body model works just as good as it looks.

Online Extras

  • Brass-Body Hand Plane
    This fine tool is beautiful to look at and a joy to use. But the greatest satisfaction comes from knowing that you built it yourself.
  • Brass-Body Block Plane
    As a companion to the hand plane in ShopNotes No. 79, we’ve also designed a brass-body block plane. This plane is built using the same techniques covered in that article -- just on a smaller scale.

Working with Brass37

Working with brass doesn't have to be a challenge. Here you'll learn how to cut, shape, solder, and polish brass to a fine finish.

Rotary Tools40

What's new in rotary power tools? Take a peek at a few must-have accessories for your rotary tool.

Best Place For a Table Saw42

Locating your table saw is the key to efficient work. We show you the best place to put it.

Online Extras

  • Scale Tool Drawings
    Locating your table saw will go a long way toward making your workshop more efficient and enjoyable. Use these scale drawings to help lay out your shop.

3 Ways to Cut a Rabbet44

A table saw is the perfect choice for cutting rabbets. Learn three sure-fire ways to do it right.

Space-Saving Storage46

Here's a product that will allow you to reclaim storage space between the studs in your walls.

Roll-Out Shop Flooring48

Make your floor look new again. All you have to do is roll a "new" one in place and cut it to fit.

Q&A50

Scenes from the Shop52
